Navigate to 'Workspace Catalogs/Palettes/' and drag and drop the tool palette into AutoCAD Architecture or MEP.Navigate to the file that says 'Workspace Catalogs' and drag and drop the catalog into the Content Browser Catalog area in AutoCAD Architecture or MEP.Navigate to the folder that says 'Tool Palettes' and select the custom tool palette and drag and drop it into the AutoCAD Architecture or MEP tool palettes.

Navigate to the tool palette file location in file explorer of C:\Users\username\AppData\Roaming\Autodesk\ACA 20XX\enu\Support\ or C:\Users\username\AppData\Roaming\Autodesk\MEP 20XX\enu\Support\ and do one of the following:.

Add the file paths in the tool palette file location like above.

In model space on the command line use CUSTOMIZE and drag the tool palettes from the left column to the right column then press 'Ok' and 'Close'.ĭrag and Drop the tool Palettes back into AutoCAD Architecture or MEP:.

datalink (for dynamic and attribute block data).

Click 'Add' then 'Browse' and navigate to the file paths for the custom tool catalogs, tool palettes, etc.,:.

In the 'File' tab navigate down to the 'Tool Palette File Location' tree and expand it.

On the command line type OP or OPTIONS and hit 'Enter'.

Note: For versions 2019 and higher, select all the tools right click on them and Add to tool palette Use Customize to add the custom Tool Palettes:

Open the catalog and drag the AutoCAD tool palettes from Content Browser onto your local AutoCAD Architecture or AutoCAD MEP tool palettes.

Browse for the ATC file that contains your AutoCAD tool palettes, select Open, then OK.

Choose the radio button to "Add an existing catalog or web site".

In the lower left, click the icon to add or create a catalog.

From the Insert ribbon, Content tab, click the Content Browser to launch it.

Try one or more of the following solutions to attempt to fix your issue: Use the Content Browser to add your AutoCAD tool palettes to AutoCAD Architecture or AutoCAD MEP:
